By Michele R. Coppola (senior writer and editor at the National Law Enforcement and Corrections Technology Center System’s National Center.)
In the mid-1970s, NIJ began developing performance standards for body armor to help provide confidence that law enforcement officers are properly and consistently protected each and every time they face gunfire in the line of duty. Since that time, body armor has been credited with saving the lives of more than 3,100 law enforcement officers.
NIJ’s most recent body armor standard — Ballistic Resistance of Body Armor, NIJ Standard-0101.06, published in July 2008 — establishes minimum performance requirements and test methods for the ballistic resistance of body armor designed to protect the torso against gunfire. Although this standard and all other NIJ standards are voluntary — that is, manufacturers are not required to follow them — many public safety agencies require compliance with NIJ standards before they purchase equipment. Through the NIJ Compliance Testing Program (CTP), manufacturers can voluntarily submit equipment samples for testing by NIJ-approved laboratories to determine whether their models comply with a particular standard.
The National Law Enforcement and Corrections Technology Center System’s National Center (NLECTC-National) oversees NIJ’s body armor conformity assessment efforts.
With funding from NIJ, NLECTC-National administers two distinct phases of conformity assessment through the CTP. Phase 1 involves documenting the design of an armor model and testing up to 28 samples voluntarily submitted by manufacturers to verify that the model meets the standard’s minimum performance requirements. Models that meet the standard are added to the Compliant Products List, which can be found here.
“The follow-up program providesan additional set of eyes and earsinto the manufacturing process,”said Lance Miller, NLECTC-National director. “We want to ensure thatthe men and women who wearthese vests on a daily basis have asmuch confidence in these productsas we can possibly give them.”
How the Program Works
The follow-up program applies to armor models deemed compliant with the 2008 NIJ standard. Each month, the CTP staff reviews thenumber of models a manufacturer currently has on the Compliant Products List that have not been inspected within the past 10 months and prepares a list of models and manufacturers for follow-up inspection. Independent inspectors conduct surprise inspections at these manufacturers’ locations. If a manufacturer does not agree to this follow-up inspection and testing, its armor will not remain on the Compliant Products List. The inspectors randomly select two newly manufactured vests for each identified model of interestand send them to NIJ-approved,accredited laboratories for testing.The laboratories send the test resultsto Underwriters Laboratories, anindependent, not-for-profit testingand certification organization, forprocessing. Meanwhile, the laboratoriessend the vests to CTP staff, who also inspect the armor’sconstruction. Both steps — thelaboratory testing and the inspectionof construction — help ensure thatthe manufacturer has built the newlymanufactured vest the same way asvests previously submitted for phase1 testing.
What inspectors found
Inspectors conducted their first follow-up inspection in September 2010. Through August 2012, they had visited 90 manufacturing locations in five countries (United States, Canada, Mexico, Colombia and the People’s Republic of China) and tested 222 body armor models, according to Jamie Phillips, NLECTC National conformity assessment coordinator. Of those models, five sustained multiple perforations during laboratory testing. Subsequently,the manufacturers issued recalls and replaced more than 1,750 fielded armors to ensure that practitioners had effective ballistic body armor that complied with the NIJ standard. The manufacturers also took corrective actions to fix what was causing the perforations.
“Staff at NIJ and NLECTC have worked actively with manufacturers to identify the root cause of these performance issues,”
“In cases where it was a significant issue, manufacturers voluntarily took immediate action to recall and replace units or take some sort of corrective action out in the field.”
To date, inspectors have discovered eight models with major variations in construction that could affect ballistic performance. For example, in one case, the number of layers in the follow-up testing vest samples differed from those in the original samples; in another, leaking covers allowed water to penetrate to the ballistic panel. Inspectors also identified 33 models with minor variations in construction that would not affect ballistic performance. In response, manufacturers worked with the CTP team to implement quality-contro limprovements at several locations to prevent these and other variations inconstruction.
Moving Forward Together
Inherent to the follow-up inspection process is increased communication between body armor manufacturers and the assessors.
“The program provides an opportunity to work more closely with manufacturers to ensure that fielded armor is more likely to comply withthe NIJ standard,” Phillips said. “It allows manufacturers to express their concerns, and we, in turn, are able to explain the reasons behind our decisions and how those decisions support the law enforcement community as a whole.
”NIJ does not anticipate major changes to the follow-up process, but staff will continue to explore opportunities for improvement. “Ithink we view it in the same light as the entire Compliance Testing Program,” Miller noted. “We view the standard itself as a living, breathing document that is flexible and can adapt to changing trends in the industry and new testing methods, and I don’t see the follow-up program as any different.”
“We obviously have learned much,” he added. “As we continue this dialogue with manufacturers, we continue to learn more about the body armor manufacturing processes and how quality management in that industry works. And as we learn more, we will adapt the program.”
